Product Introduction

FRT18 series are packaged with imported thin film,The temperature sensor used to measure the special transformer with high voltage resistance has been widely used with some large international companies.

Product Characteristics

• Temperature factor：TK=3850ppm/k
• Precision rating：1/3B：T0℃≤0.10℃（0~150℃）
• Level A：T0℃≤0.15℃（-50~300℃）
• Level B：T0℃≤0.30℃（-200~500℃）
• Insulation resistance：≥100MΩ@500V&20℃
• Heat coefficient：0.4K/mW （0℃）
• Working current ：100Ω：0.3~1mA
• 500Ω：0.1~0.7mA
• 1000Ω：0.1~0.3mA
• Pressure withstand standard：≥0.5MPa
